TEAC CORPORATION
CD-532S
|
Device Type |
Internal CD-ROM |
|
Interface |
SCSI |
|
Spin Rate (Read) |
2x, 4x, 8x, 32x |
|
Formats Supported Read |
CD-XA, CD-DA, CD-R, CD-RW, CD-I, CD-ROM (Mode 1 & Mode 2), Photo-CD, Video-CD, CD-Plus |
|
View |
Top |
|
CONNECTIONS |
|
|
Function |
Label |
|
Audio line out |
CN1 |
|
USER CONFIGURABLE SETTINGS |
||
|
Setting |
Label |
Position |
|
í Parity check enabled |
S/3 |
Open |
|
Parity check disabled |
S/3 |
Closed |
|
í Block size set at 2048 |
S/4 |
Open |
|
Block size set at 512 |
S/4 |
Closed |
|
í Termination disabled |
S/5 |
Open |
|
Termination enabled |
S/5 |
Closed |
|
í Factory configured - do not alter |
S/6 |
Open |
|
DRIVE SELECT ID |
|||
|
Drive ID |
S/0 |
S/1 |
S/2 |
|
0 |
Open |
Open |
Open |
|
1 |
Closed |
Open |
Open |
|
2 |
Open |
Closed |
Open |
|
í 3 |
Closed |
Closed |
Open |
|
4 |
Open |
Open |
Closed |
|
5 |
Closed |
Open |
Closed |
|
6 |
Open |
Closed |
Closed |
|
7 |
Closed |
Closed |
Closed |
