| Step | Size (Quantity) | Color | Torque |
|---|---|---|---|
| 1 | M2.5 x 8 mm , Nylon (2) | Black | 4 kgcm |
| 2 | M2.5 x 6 mm , Nylon (4) | Black | 4 kgcm |
NOTE: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you have removed, use
a new screw.
| Step | Size (Quantity) | Color | Torque |
|---|---|---|---|
| 3 | M2.5 x 8 mm , Nylon (3) | Black | 4 kgcm |
| 4 | M2.5 x 4 mm , Nylon (1) | Black | 4 kgcm |
NOTE: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you have removed, use
a new screw.
